Ribbed Steel Reinforcement Bar for Building Projects

Product Highlights

• Product Type: Hot-rolled ribbed steel reinforcement bar
• Execution Standard: GB/T 1499.2-2018
• Customization: Length, diameter, steel grade, and order quantity

Product Features

Ribbed Surface for Concrete Bonding

The longitudinal and transverse ribs on the surface of the reinforcement bar help create mechanical interlocking between steel and concrete. This bonding mechanism supports load transfer within reinforced concrete structures and helps reduce relative movement between the reinforcing steel and the surrounding concrete when properly designed and installed.

Multiple Steel Grades for Structural Reinforcement

Shunchen supplies different grades of ribbed steel reinforcement bars to meet varying structural design requirements. HRB400 and HRB500 are used in conventional reinforced concrete applications, while HRB400E and HRB500E are seismic-grade options with additional ductility and strength-ratio requirements. The appropriate grade should be selected according to structural drawings, project specifications, and applicable building codes.

Consistent Mechanical Properties

The Ribbed Steel Reinforcement Bar for Building Projects production process includes billet heating, rolling, and controlled cooling or subsequent heat treatment according to the product type. Mechanical properties such as yield strength, tensile strength, elongation, and bending performance are evaluated against the applicable standard and specified steel grade. This helps construction teams select reinforcement materials that meet project design requirements.

Multiple Diameters and Length Options

The standard diameter range covers 6–50 mm, with 8–32 mm commonly used in building reinforcement. Standard lengths are 9 m and 12 m, while customized fixed lengths can be discussed for suitable orders. The available range supports different reinforcement requirements, from smaller-diameter bars used in secondary reinforcement to larger bars used in structural members.

Suitable for Seismic-Resistant Structures

HRB400E and HRB500E seismic-grade reinforcement bars are designed to meet additional ductility and yield-strength-ratio requirements under the relevant standard. These properties make them suitable for structural applications where seismic performance is specified. Final grade selection and placement should follow the project's structural design and local regulations.

Flexible Processing and Installation Compatibility

Ribbed steel reinforcement bars can be incorporated into reinforced concrete structures through approved construction methods, including tying, mechanical connection, and welding where permitted by the applicable grade and project specifications. For projects requiring prepared reinforcement, Shunchen also provides related cut-and-bend rebar solutions.

Product Structure and Manufacturing Process

Shunchen Ribbed Steel Reinforcement Bars are manufactured from carbon steel or low-alloy steel billets. The billets are heated and rolled through a series of rolling stands to form the required diameter and ribbed surface profile. Depending on the product grade and production route, controlled cooling or subsequent heat treatment may be applied to achieve the required mechanical properties.

The finished bars feature longitudinal ribs and transverse ribs along the surface. These ribs are designed to improve the mechanical bond between reinforcement and concrete. The bar diameter, length, rib geometry, surface condition, and mechanical properties are controlled according to the applicable product standard and order requirements.

After production, the bars are inspected, identified by grade and specification, and prepared for bundling and shipment. Product labels and relevant quality documentation help customers verify the supplied material against their purchase orders and project requirements.

Technical Specifications

Steel Grades and Applicable Standards

Different reinforcement grades are used according to structural design requirements, strength levels, ductility requirements, and applicable construction standards. The following table summarizes the main grades in Shunchen's reinforcement product range.

Other reinforcement products, including HPB300 plain round bars and CRB550 / CRB650 cold-rolled ribbed bars, are available within the broader product range. Their applicable standards and specifications should be confirmed separately according to the selected product type.

Dimensional Specifications and Theoretical Weight

Ribbed steel reinforcement bars are supplied in different diameters to meet the reinforcement requirements of structural members. The following theoretical weights are calculated using the commonly applied formula for steel reinforcement bars:

The values above are theoretical reference weights. Actual weight and dimensional tolerances are subject to the applicable product standard, nominal diameter, and inspection requirements. Please confirm the required specifications before ordering.

Quality Control and Testing

Shunchen applies quality inspection procedures throughout the reinforcement steel production and supply process. Inspection requirements are arranged according to the product grade, applicable standard, and order specifications to help ensure that delivered materials meet the agreed technical requirements.

Certifications

Applications of Ribbed Steel Reinforcement Bar

Ribbed Steel Reinforcement Bar For Building Projects is used in reinforced concrete structures where steel reinforcement is required to improve tensile load-bearing performance and work together with concrete. The selected grade and diameter depend on structural design, loading conditions, and applicable construction standards.

• Residential & Commercial Buildings: Beams, slabs, columns, shear walls and foundations
• Bridge & Highway Engineering: Bridge piers, girders and pile foundations
• Rail Transit Infrastructure: Subway tunnels, station structures and track beams
• Industrial Construction: Factory foundations, equipment bases and warehouse floors
• Water Conservancy Projects: Dams, water conveyance structures and retaining walls
• Seismic-Resistant Construction: Seismic-grade reinforcement for structural members

Project Experience

Shunchen's supplied reinforcement steel has been used in major construction and infrastructure projects. The following project references are based on the company's supplied project information and should be supported by relevant documentation when used in external marketing materials.

Why Choose Shunchen

Integrated Steel Production and Supply

Tianjin Shunchen Hongye was established in 2014 and operates in Daqiuzhuang, Tianjin. The company combines steel production and sales capabilities to supply reinforcement materials for construction and infrastructure projects. Its production system supports a range of steel specifications for different project requirements.

Complete Reinforcement Product Range

Shunchen supplies multiple reinforcement grades and diameters, covering conventional hot-rolled ribbed bars and seismic-grade reinforcement. Customized lengths and specification matching can be discussed according to project drawings and procurement schedules.

Production and Quality Management

The company applies production monitoring and inspection procedures to manage material consistency and product specifications. Quality documentation and testing support help customers review material compliance before delivery and during project acceptance.

Flexible Supply and Order Coordination

Shunchen supports project-based procurement, bulk orders, and coordination of delivery schedules. Inventory availability and production arrangements can be confirmed according to the required steel grade, diameter, length, and order quantity.

Technical and Procurement Support

The team can assist customers with reinforcement grade selection, specification confirmation, product documentation, and coordination of delivery requirements. This support helps contractors, distributors, and procurement teams organize steel orders according to project needs.

Traceability and After-Sales Support

Product identification and available quality records support material traceability. Shunchen provides an 18-month warranty under its stated warranty policy, along with after-sales assistance for confirmed product quality issues.

Factory & Warehouse

Customization and Procurement Support

Shunchen supports reinforcement procurement based on project specifications and construction schedules. Customers can submit their required steel grades, diameters, lengths, quantities, and applicable standards for confirmation before placing an order.

• Steel Grade: HRB400, HRB500, HRB400E, HRB500E, and other available grades subject to confirmation.
• Diameter: Standard sizes from 6 mm to 50 mm, with special sizes subject to production feasibility.
• Length: Standard 9 m and 12 m bars, with customized fixed lengths subject to agreement.
• Processing: Cut-and-bend reinforcement solutions can be discussed for suitable projects.
• Documentation: Material certificates and testing records can be provided according to the order requirements.
• Packaging and Delivery: Bundling, identification, and delivery arrangements can be coordinated according to the order and destination.

Packaging and Delivery

Ribbed steel reinforcement bars are bundled and identified according to their specifications and steel grades to facilitate handling, storage, and site distribution. Packaging and marking requirements can be discussed before shipment to help customers organize material receipt and inventory management.

Delivery schedules depend on the required specifications, order volume, stock availability, production arrangements, and destination. Shunchen coordinates shipment planning with customers to support project delivery schedules. Please confirm the estimated dispatch date, transportation method, and shipping terms before order confirmation.

Ordering Information
