Standard Size Galvanized Steel C Channel
Standard Size Galvanized Steel C Channel offers exceptional structural strength and long-term durability for a wide array of construction and industrial projects. Known for its high load-bearing capacity and consistent performance, this channel is a cornerstone material for framing, support systems, and bracing. Its versatility makes it an ideal choice for both primary and secondary structural applications, ensuring stability and reliability in demanding environments. For projects requiring specific dimensions and enhanced corrosion resistance, our C100 C150 C200 Galvanized Purlin series provides standardized solutions. The superior protective coating of our Hot Dipped Galvanized C Purlin ensures maximum defence against rust and environmental degradation. Engineered for efficiency, our Light Gauge Galvanized Steel Purlin combines strength with a lightweight profile, facilitating easier handling and installation without compromising integrity. Furthermore, the Galvanized C Purlin for Solar Mounting is specifically designed to meet the rigorous demands of renewable energy infrastructure, providing a robust and lasting framework for solar panel arrays.
The Standard Size Galvanized Steel C Channel is manufactured from high-quality steel coils that undergo a rigorous galvanizing process. This involves coating the steel in a layer of molten zinc, which bonds metallurgically to the base metal, creating a barrier that sacrificially protects the steel from corrosion. This process is critical for products used outdoors or in humid conditions, significantly extending the service life of the channel. The manufacturing standards for the Standard Size Galvanized Steel C Channel adhere to strict international specifications, ensuring dimensional accuracy, uniform coating thickness, and consistent mechanical properties. Typical applications span commercial and industrial construction, including warehouse mezzanines, roof purlins, wall girts, and support frames for machinery. The channel's design allows for straightforward connection with other structural components using standard bolts and fasteners, streamlining the construction process. Available in a range of standard lengths and gauges, the Standard Size Galvanized Steel C Channel can be easily integrated into architectural plans and prefabricated building systems, offering designers and builders a reliable and cost-effective structural solution.
Key Specifications of Standard Size Galvanized Steel C Channel:
- Material: High-Strength Commercial Quality Steel
- Coating: Hot-Dip Galvanized (Zinc Coating)
- Standard Coating Weight: Z275 (275 g/m² minimum)
- Yield Strength: Min. 345 MPa (50 ksi)
- Surface Finish: Smooth, Spangled Finish
- Primary Standards: ASTM A653, ASTM A792, AS 1397
| Depth (Flange to Flange) | Flange Width | Lip Length | Thickness (Gauge) | Approx. Weight per Meter |
|---|---|---|---|---|
| 100 mm (4") | 50 mm (2") | 15 mm (0.6") | 1.8 mm (14 Ga.) | 3.05 kg/m |
| 150 mm (6") | 65 mm (2.56") | 15 mm (0.6") | 1.8 mm (14 Ga.) | 4.12 kg/m |
| 200 mm (8") | 75 mm (2.95") | 20 mm (0.79") | 2.0 mm (12 Ga.) | 5.98 kg/m |
| 250 mm (10") | 80 mm (3.15") | 20 mm (0.79") | 2.3 mm (10 Ga.) | 7.85 kg/m |
Common Applications:
- Structural Framing and Support Beams
- Roof Purlins and Wall Girts
- Mezzanine Flooring Systems
- Industrial Rack and Storage Systems
- Support Channels for Electrical Conduits
- Framework for Partitions and False Ceilings
