PV Carport Mounting System
Shunchen Industrial's High-quality PV Carport Mounting System is an integrated installation support system specifically tailored for solar photovoltaic modules. This system integrates high-quality components such as custom-designed embedded panels, high-strength brackets, threaded steel, and precision connectors, cleverly divided into two main categories based on application scenarios: rooftop and ground-mounted. Through precise design and professional installation, it provides a stable and reliable foundation for photovoltaic modules while flexibly adapting to angle adjustment needs, ensuring that the modules always receive sunlight in the optimal position, achieving efficient power generation and long-term stable operation.
Shunchen Industrial's PV Carport Mounting System emphasizes integrated customization services. Leveraging the strong advantages of its own steel supply chain, the brackets, connectors, and custom-designed embedded panels, threaded steel, and other components achieve perfect compatibility, eliminating the need for cumbersome additional adjustments. The system uses high-strength, corrosion-resistant materials and precision machining processes, providing excellent protective performance and easily handling the challenges of all outdoor conditions. Whether for rooftop or ground-mounted applications, customized design solutions are available. From solution design and component production to on-site installation, Shunchen Industrial provides attentive service throughout the entire process, with strict quality control and seamless supply coordination with upstream and downstream products, effectively shortening the project cycle and creating highly reliable and adaptable support solutions for photovoltaic projects.
Shunchen Industrial's PV Carport Mounting System boasts superior functionality and precise positioning. Its core functions are powerful and diverse: In terms of stable load-bearing, it accurately transfers the weight of the photovoltaic modules and external loads such as wind, snow, and earthquakes to the embedded components and main structure via the support system, preventing displacement and deformation; in terms of power generation compatibility, it supports precise adjustment of the module installation angle to maximize the reception of solar radiation and significantly improve power generation efficiency; at the connection points, it is compatible with photovoltaic modules of different specifications and works deeply with customized embedded panels, threaded steel, and other basic components to construct a complete load-bearing system; in protective conditions, it can withstand the effects of outdoor high temperatures, humidity, and corrosion, ensuring long-term stable operation and extending the system's service life.
Technical Specifications
|
Specifications and Categories |
Technical parameters |
Applicable Scenarios and Collaboration Description |
|
Material and mechanical properties |
Mainstream materials: HRB400, HRB500; Yield strength: HRB400 ≥ 400 MPa, HRB500 ≥ 500 MPa; Tensile strength: HRB400 ≥ 540 MPa, HRB500 ≥ 630 MPa; Elongation after fracture ≥ 14%; Seismic resistance rating can be customized as needed. |
It is compatible with core load-bearing components such as photovoltaic foundations, industrial plant beams and columns, and municipal utility tunnels, and is welded to customized embedded panels as anchor bars to provide a solid foundation for the PV installation system. |
|
Size and shape specifications |
Diameter: 6mm~50mm (standard), of which 6mm~14mm can be coiled, and 12mm~50mm can be made into straight strips; Straight strip length: 9m, 12m (customizable); Longitudinal rib height ≥0.8mm, transverse ribs evenly distributed, rib pattern regular and without defects. |
The coil type is compatible with automated cutting and processing; the straight type can be directly reinforced on-site; it precisely matches the hole layout of customized embedded panels, adapting to the foundation pre-embedding requirements of PV installation systems. |
|
Machining accuracy standards |
The length tolerance after cutting is ≤±3mm, and the perpendicularity deviation of the end face is ≤0.5°; the surface is free of cracks, oxide scale, and rust, and it has excellent welding performance, allowing direct welding to embedded panels. |
To avoid secondary processing losses, ensure precise connection with PV mounting system brackets and embedded boards, and improve overall installation efficiency and structural stability. |
|
Corrosion prevention and packaging protection |
Standard natural rust prevention; hot-dip galvanizing treatment (zinc layer thickness ≥80μm) is available for coastal and high-humidity environments. Straight bars are bundled and packaged, then coiled and coated for protection to prevent rust during transportation and storage. |
Suitable for complex working conditions such as outdoor and underground applications, it works in conjunction with PV installation systems and custom embedded panels to resist environmental erosion and extend the overall service life of the project. |
|
Implementation standards and supporting measures |
Strictly adheres to national standard GB/T 1499.2-2018; custom anchor bar lengths are available, compatible with high-strength bolts, cut rebars, and other components; integrated supply is supported. |
Together with Shunchen's customized embedded panels, PV installation systems, and steel bar cutting, we form a complete supply chain to meet the acceptance and integrated construction needs of photovoltaic and infrastructure projects. |
This system boasts numerous selling points: Highly customizable and adaptable, PV Carport Mounting System can be tailored to rooftop and ground-level applications, combining component specifications and load requirements to create customized support structures and installation schemes, making it suitable for diverse photovoltaic projects; High-strength, stable, and durable, utilizing Q235B/Q345B high-strength support materials with anti-corrosion treatment, offering excellent wind and earthquake resistance, and a service life exceeding 25 years, matching that of the components; Collaborative and efficient installation, seamlessly integrated with Shunchun's proprietary embedded panels, threaded steel, and cutting rebar, simplifying the installation process and improving precision and efficiency; Highly efficient power generation, with angles that can be optimized as needed to reduce shading and load losses, balancing ease of installation with maximum power generation efficiency.
In application areas, the results are remarkable. In the field of rooftop photovoltaic systems for logistics parks, PV Carport Mounting System adapts to complex working conditions, achieving efficient installation and stable load-bearing capacity; in the field of heavy-duty foundations for industrial plants, it constructs a high-strength load-bearing system, improving overall integrity and load-bearing capacity; in the field of main structures for municipal utility tunnels, its high strength and crack resistance ensure the durability of the project. Numerous typical cases, such as the Shandong Photovoltaic Logistics Park, the Jiangsu Electronics Factory, and the Tianjin Municipal Utility Tunnel project, have all verified the reliability and superior performance of Shunchun Industrial's PV installation system.
Its own industrial advantages
Shunchen Industrial's PV Carport Mounting System focuses on integrated customization services. Leveraging its own steel supply chain, brackets, connectors, and customized embedded plates and threaded steel are precisely matched, requiring no additional adjustments. Utilizing high-strength, corrosion-resistant materials and precision machining processes, its protective performance is suitable for all outdoor conditions, supporting customized designs for rooftop and ground-mounted applications. It provides a full-process service from solution design and component production to on-site installation, with comprehensive quality control and collaborative supply with upstream and downstream products, significantly shortening project cycles and providing highly reliable and adaptable support solutions for photovoltaic projects.
